| 荷重(kg) | 型号 |
速度 (m/min) |
挂数 | 链条 (直径 x 节距) (mm) |
马达 (kw x pole) |
吊机净 重 (kg) |
规格尺寸 (mm) | ||||||||
| A | B | C | D | F | H | I | J | M | |||||||
| 250 | SH-025-1 | 4 | 1 | 4 x 12 | 0.25 x 4 | 28 | 410 | 135 | 18 | 205 | 175 | 28 | 165 | 85 | 25 |
| 500 | SH-050-1 | 4 | 1 | 6.3 x 19.1 | 0.4 x 4 | 42 | 520 | 156 | 23 | 297 | 221 | 33 | 185 | 105 | 30 |
| 1000 | SH-100-1 | 4 | 1 | 7.1 x 20.2 | 0.75 x 4 | 54 | 650 | 170 | 23 | 275 | 240 | 33 | 205 | 135 | 30 |
| 2000 | SH-200-1 | 4 | 2 | 7.1 x 20.2 | 1.5 x 2 | 62 | 700 | 170 | 27 | 275 | 240 | 39 | 170 | 170 | 30 |
